/Hardware/HookS.foocad

import static uk.co.nickthecoder.foocad.layout.v1.Layout2d.*
import static uk.co.nickthecoder.foocad.layout.v1.Layout3d.*
import uk.co.nickthecoder.foocad.smartextrusion.v1.*
import static uk.co.nickthecoder.foocad.smartextrusion.v1.SmartExtrusion.*

class HookS : Model {

    @Custom
    var size = Vector2( 90, 150 )

    @Custom
    var hook1 = Vector2( 20, 25 )

    @Custom
    var radius1 = 12

    @Custom
    var hook2 = Vector2( 8, 10 )

    @Custom
    var radius2 = 5

    @Custom
    var thickness = 1.2

    @Custom
    var edge = Vector2(4, 5)

    @Custom
    var chamfer = 0.8


    @Custom
    var diamondCutouts = true

    @Custom
    var diamondSize = 20

    @Custom
    var gap = 5

    @Custom
    var margin = Vector2( 10, 10 )

    meth hook() : Shape3d {

        val s = PolygonBuilder().apply {
            moveTo( 0, 0 )
            radius( radius1 )
            lineBy( 0, -hook1.y )
            lineBy( hook1.x + edge.x, 0 )

            radius( radius2 )
            lineBy( 0, size.y + edge.x/2 )

            lineBy( hook2.x + edge.x, 0 )
            radius(0)
            lineBy( 0, -hook2.y )
        }.buildPath()

        val thin = s.thickness(thickness).smartExtrude(size.x)

        val end = Circle( edge.x/2 ) hull Circle( edge.x/2 ).translateY( edge.y - edge.x )
        val ends = (
            end.translate( s[0] ).translateY( - edge.y + edge.x ) +
            end.translate( s[-1] )
        ).smartExtrude( thin.top ).edges( Chamfer(chamfer) )

        val edges = s.thickness(edge.x)
            .smartExtrude( edge.y )
            .bottom( Chamfer(chamfer) )
            .top( Chamfer(0.5) )
            .mirrorZ().topTo( thin.top ).also(2)


        if ( diamondCutouts ) {
            val diamonds = Square( diamondSize )
                .tileX( 5, gap ).tileY( 5, gap )
                .center().rotate(45)

            val envelope = Square( size.x - margin.x*2, size.y - margin.y*2 ).center()

            val cutouts = diamonds.intersection( envelope )
                .smartExtrude( thickness + 0.02 )
                    .edges(Chamfer(thickness/3).reverse())
                .rotateY(90)
                .centerZTo( size.x/2 )
                .centerYTo( thin.middle.y )
                .translateX( hook1.x - 0.01 - thickness*0.5 + edge.x )

            return thin + ends + edges - cutouts

        } else {
            return thin + ends + edges
        }
    }

    @Piece( print="hook" )
    override fun build() : Shape3d {

        val hook = hook()
            .rotateX(90).centerY().rotateZ(-90)

        val drive = Cube( 145, 20, 145 ).centerX()
            .backTo( hook.back - edge.x )
            .translateZ(-15)
            .previewOnly()

        return hook + drive
    }

}
